Processor
Intel® Core™ i5 14th generation processor
Intel® Core™ i5-14500 (up to 5.0 GHz with Intel® Turbo Boost Technology, 24 MB L3 cache, 14 cores, 20 threads) [6,7]
Software and Applications
HP PC Hardware Diagnostics UEFI; HP Support Assistant; HP PC Hardware Diagnostics Windows; HP Privacy Settings; HP Desktop Support Utilities; HP Image Assistant; HP Manageability Integration Kit; HP Notifications; Performance Advisor 3.0; HP Data Science Stack Manager; myHP [16,17]
Touchpoint Customizer for Commercial
HP Client Catalog (download); HP Cloud Recovery; HP Driver Packs; HP Management Integration Kit for Microsoft System Center Configuration Management Gen4; HP System Software Manager (download); HP BIOS Configuration Utility (download); HP Image Assistant (download); HP Client Management Script Library (download) [18]
Connectivity and Communications
1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge); 4 SuperSpeed USB Type-A 10Gbps signaling rate (1 charging); 1 universal audio jack
3 USB Type-A 5Gbps signaling rate; 2 DisplayPort™ 1.4; 1 RJ-45; 1 audio-in; 1 audio-out; 1 HP Fiber NIC Port Flex IO; 3 USB Type-A 480Mbps signaling rate
1 half-height PCle 4 x16; 1 half-height PCle 3 x4; 1 half-height PCle 3 x4 (x16 connector); 1 half-height PCle 3 x1; 1 full-height PCle 4 x16; 1 full-height PCle 4 x16 (x16 connector) [29]
1 M.2 2230 slot for WLAN and 3 M.2 2280 slots for storage
Display Specifications
Supports 8 displays, driving 8 displays requires the use of integrated and discrete graphics ports. Each source can drive a total of 4 displays. At least one of the integrated graphics ports need to drive two displays in a daisy chain configuration.
All HP Z Displays and HP DreamColor Displays are supported. For more information see www.hp.com/go/zdisplays
Dimensions
Package dimensions (W x D x H)
Graphic Subsystem
Graphic card footnote number
Multimedia and Input Devices
Memory
16 GB DDR5-4800 MT/s (1 x 16 GB)
Memory layout (slots & size)
16 GB memory; 512 GB SSD storage
Transfer rates up to 4800 MT/s.
Battery and Power
450 W 90% efficient, wide-ranging, active PFC [10]
Security Management
HP Secure Erase; HP Sure Click; HP BIOSphere Gen6; HP Sure Admin; Hood Sensor Optional Kit; HP Client Security Manager Gen6; HP Sure Start Gen7; HP Sure Recover Gen4; HP Tamper Lock; HP Sure Sense Gen2; HP Sure Run Gen5 [19,20,21,22,23,24,25,26,31]
Security Software Licenses
HP Wolf Pro Security Edition (1 year)
Security software licenses footnote number
Warranty
3 year (3/3/3) limited warranty includes 3 years of parts, labor and on-site repair. Terms and conditions vary by country. Certain restrictions and exclusions apply.
Drives and Storage Specifications
512 GB HP Z Turbo Drive PCIe® NVMe™ TLC M.2 SSD
Integrated SATA (4 ports 6 Gb/s) with integrated RAID 0, 1, for PCIe SSDs supported. Requires identical hard drives (speeds, capacity, interface).
One 2.5" HDD; One 3.5" HDD; Three M.2 NVME 2280 SSD
One 3.5" HDD; One slim ODD
