StarTech.com Dual Port PCI Express Gigabit Ethernet PCIe Network Card Adapter - PoE/PSE
StarTech.com Dual Port PCI Express Gigabit Ethernet PCIe Network Card Adapter - PoE/PSE is backordered and will ship as soon as it is back in stock.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
StarTech.com Dual Port PCI Express Gigabit Ethernet PCIe Network Ca...
Description
Description
StarTech.com Dual Port PCI Express Gigabit Ethernet PCIe Network Card Adapter - PoE/PSE
The ST2000PEXPSE Dual Port PoE NIC provides two 10/100/1000 Mbps PoE RJ45 ports that can provide up to 25.5W of power each, combining a network data connection and power on a single cable, for less clutter and convenient installations in remote locations.
This full/low profile Gigabit server adapter supports the IEEE 802.3at (Type 1 and 2) standard for a Power Sourcing Equipment (PSE) device, and can deliver 48V DC power to compliant Powered Devices (PD). This eliminates the need for a separate power source and cable for remote networked devices such as IP cameras, IP phones and wireless access points.
Suitable for any PCI Express-enabled client, server or workstation, this versatile PoE network adapter supports features such as Jumbo Frames, VLAN tagging and Wake on LAN (WOL).
The ST2000PEXPSE PoE NIC is backed by a StarTech.com 2-year warranty and free lifetime technical support.
More from the Manufacturer
- Includes full and low profile/half-height installation brackets
- Crossover Detection & Auto-Correction (Auto MDIX)
- Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control
- Jumbo Frame support
- On-chip 48 KB Big Transmit/Receive Buffer Support
- Built-in SATA and LP4 Molex power connector
- Unique surge protection design helps prevent system damage in the event of lightning strikes
- Power Sourcing Equipment (PSE) design, provides data and up to 25.5W of power on each port
- Supports IEEE 802.3at (Type 1, 2) Power over Ethernet standard
- Dual 10/100/1000 Mbps PoE RJ45 ports
| Product Type: Gigabit Ethernet Card |
| Environmentally Friendly: Yes |
| Chipset Manufacturer: Realtek |
| Chipset Model: RTL8111E |
| Number Of Network (Rj 45) Ports: 2 |
| Media Type Supported: Twisted Pair |
| Total Number Of Ports: 2 |
| Environmental Compliance: Restriction of Hazardous Substances (RoHS) |
| Country Of Origin: Taiwan |
| Brand Name: StarTech.com |
| Form Factor: Plug-in Card |
| Manufacturer: StarTech.com |
| Product Name: Dual Port PCI Express Gigabit Ethernet PCIe Network Card Adapter - PoE/PSE |
| Network Technology: 10/100/1000Base-T |
| Device Supported: PC |
| Manufacturer Part Number: ST2000PEXPSE |
| Manufacturer Website Address: http://www.startech.com |
| Packaged Quantity: 1 Each |
Package Contents:
|
| Host Interface: PCI Express |
| Thickness: 0.70" (17.78 mm) |
| Weight (Approximate): 3.70 oz (104.89 g) |
| Feature1: Includes full and low profile/half-height installation brackets |
| Feature2: Crossover Detection & Auto-Correction (Auto MDIX) |
| Feature3: Fully Compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, and supports IEEE 802.1Q VLAN tagging, IEEE 802.1P Layer 2 Priority Encoding and IEEE 802.3x Full Duplex Flow Control |
| Feature4: Jumbo Frame support |
| Feature5: On-chip 48 KB Big Transmit/Receive Buffer Support |
| Feature6: Built-in SATA and LP4 Molex power connector |
| Feature7: Unique surge protection design helps prevent system damage in the event of lightning strikes |
| Feature8: Power Sourcing Equipment (PSE) design, provides data and up to 25.5W of power on each port |
| Feature9: Supports IEEE 802.3at (Type 1, 2) Power over Ethernet standard |
| Feature10: Dual 10/100/1000 Mbps PoE RJ45 ports |
