StarTech.com  |  PART NUMBER: RS232EXTC1

StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)

$153.07 $168.99
Shipping calculated at checkout.

In stock: 3

Delivery and Shipping

Add some general information about your delivery and shipping policies.

Description

StarTech.com Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)
The RS232EXTC1 Serial over Cat 5 Extender allows you to increase the distance of your RS232 Serial connection by up to 1000 meters (3300 feet), giving you the ability to connect serial peripheral devices up to a kilometer away from your system - an incredible 65x greater than normal RS232 serial cable length restrictions would permit.

The Extender is a cost-effective serial extension solution and completely hardware-based, eliminating the need to install additional software, allowing for a completely plug and play installation. The hardware can be setup in minutes, using existing or new Cat 5 or better Ethernet cabling.

Perfect for use in industrial monitoring and control, POS, security, medical, and traffic flow applications, the RS232 Serial over Cat 5 extender maintains the RS232 standard with support for data transfer rates of up to 230 Kbps.

Backed by a StarTech.com 2-year warranty and free lifetime technical support.

More from the Manufacturer

More from the Manufacturer


  • No driver software required for easy Plug-and-Play installation

  • Compact design

  • Supports full-duplex data communication

  • Employ existing Cat 5, 5e, 6 or better Ethernet infrastructure to remotely connect serial devices

  • Data transfer rates of up to 230Kbps

  • Compatible with all RS232 communications

  • Extend RS232 up to 1000m / 3300ft
Product Type: Serial Extender
Environmentally Friendly: Yes
Maximum Data Transfer Rate: 230 kB/s
Number Of Network (Rj 45) Ports: 2
Network (Rj 45): Yes
Taa Compliant: Yes
Maximum Extended Range: 3280.84 ft (1000000 mm)
Product Color: Silver
Color Family: Silver
Product Material: Steel
Environmental Compliance: Waste Electrical and Electronic Equipment Directive (WEEE)
Country Of Origin: Taiwan
Brand Name: StarTech.com
Length: 3.60" (91.44 mm)
Manufacturer: StarTech.com
Product Name: Serial DB9 RS232 Extender over Cat 5 - Up to 3300 ft (1000 meters)
Input Voltage: 230 V AC
Manufacturer Part Number: RS232EXTC1
Manufacturer Website Address: http://www.startech.com
Packaged Quantity: 1 Each
Package Contents:
  • RS232 Extender Local Unit
  • RS232 Extender Remote Unit
  • 20cm Null Modem cable (DB-9 Male to Male)
  • Power Adapter
  • User Manual
Limited Warranty: 2 Year
Additional Information:
  • Enables use of separate control rooms away from harsh environmental conditions where serial devices may be located
  • Provides you with flexibility when choosing the location of your serial peripherals by dramatically increasing the maximum RS232 serial cable length
  • Pure hardware design, no software or drivers required ensuring a simple plug and play installation
Feature1: No driver software required for easy Plug-and-Play installation
Feature2: Compact design
Feature3: Supports full-duplex data communication
Feature4: Employ existing Cat 5, 5e, 6 or better Ethernet infrastructure to remotely connect serial devices
Feature5: Data transfer rates of up to 230Kbps
Feature6: Compatible with all RS232 communications
Feature7: Extend RS232 up to 1000m / 3300ft
